51.480 : TOPRING COALESCING FILTER 3/8 INCH SEMI-AUTOMATIC WITH STANDARD BOWL - AIRFLO 400
TOPRING PRODUCTS ARE DROPSHIPPED DIRECT FROM TOPRING WAREHOUSE IN QUEBEC
51.480 : TOPRING COALESCING FILTER 3/8 INCH SEMI-AUTOMATIC WITH STANDARD BOWL - AIRFLO 400
SPECIFICATIONS:
• Port Size: 3/8 (F) NPT
• Maximum Airflow at 100 PSI: 71 SCFM
• Maximum Working Pressure: 150 PSI
• Working Temperature: 5 to 60 °C
• Filtration: 0.3 micron
Drain
• Standard Bowl: Semi-automatic 8 mm O.D. tubing
• Bowl Capacity: 45 ml
Materials
• Body Material: Die cast aluminum
• Bowl Type: Polycarbonate with steel guard
• Bowl Guard: Steel
• Filter Element: coalescing filter: Fiberglass paper, 0.3 micron
• Deflector & Spinner: ABS
• O-Rings & Seals: EPDM rubber
FEATURES:
• Compact size
• High performance filter that removes 99.97% of solid particles, oil and water aerosols greater than 0.3 micron
• Standard semi-automatic drain requires a simple tug of the ring to drain
• Mounting bracket included
