08.918.12 : Topring Aluminum Pipe 160mm x 5.5m Vacuum PPS 12/pk CRN (Pack of 12)

08.918.12 : Topring Aluminum Pipe 160mm x 5.5m Vacuum PPS 12/pk CRN (Pack of 12)

Technical specifications

• Product series.. 08
• Product type.. Tubes
• Sub-Brand.. Series 08
• Compatible fluids.. Air, neutral and inert gases
• Color.. Light gray
• Body material.. Extruded aluminum EN AW 6063 T6
• Maximum Inlet Pressure (PSI).. 232
• Burst pressure (PSI).. 1160
• Maximum vacuum level (inHg).. -29.84
• Minimum fluid temperature (°C).. -20
• Maximum fluid temperature (°C).. 80
• TUVISO9001.. -2015
• ASME Compliance.. B31, B31.1, B31.3
• ATEX.. 2014/34/EU Zone 1 & 2 - 21 & 22
• THIS.. Yes
• Reach.. Yes
• C/UL/US UL Certification for finished product.. UL 723 -ASTM E84 Class 0.0.0; UL 94 HB
• NSFNSF.. -H1
• Nominal diameter (mm).. 160
• Nominal Diameter (in).. 6
• Outer diameter (mm).. 160
• Length (m).. 5.5
